| Rated load Capacity |
800 kgs |
| Platform Length |
7.5 Mts (2.5mtr + 2.5mtr + 1.5mtr + 1mtr) |
| Width |
2 Feet |
| Wheels |
4 Bottom Wheels and 2 Wall Support wheels |
| Material |
hot Dip galvanised/Powder Coated |
| Height Adjustment |
3.75 ft to 5.75 fts (adjustabledistance 100mm) |
| Hoist Model |
ZLP 800with Electromagneti Brake Motors Alpha (a) type. |
| Hoist Power |
2.5 Hp, 415 V, 50hz |
| Hoist Quality |
2 Pcs |
| Safety Lock Type |
Anti Tilting, 30 KN |
| Safety Lock Quality |
2 Pcs |
| Control Panel Quantity |
1 Pcs |
| Electric Cable |
2.5mm x 5 core , 100 Mtr |
| Steel Wire Rope |
9.1 mm, 100mtrs |
| Steel Wire Rope Quantity |
4 nos, (2 nos. Working Wire Rope & 2 no. Safety Wire Rope) |
