| Generator |
Honda EC2500 X (2.6Kw, Single CylinderFour Stroke Generator Set) |
| Package |
Box 1:2700*1050*1350mm Box 2:2900*750*920 |
| Laser Generator |
LEICA (Switzerland) (635nm visible laser, self-leveling, level error +1.5mm/30m, effective launch distance 300m) |
| Laser Receiver |
LEICA (Switzerland) (effective receving distance 300m, accuracy of dead zone +2.5mm) |
| Controle System |
AC SERVO System |
| Driving System |
PHASE (Italian) (Steeples Adjustment, turning faster than 1:2:5) |
| Airframe Adjustment |
level Sensor Automatic Adjustment System |
| Slope Working |
Single Phase Slope Automatic Adjustment |
| Wheel Tyre |
733mm ATV (1.8-2.2BAR)/3.0-21 narrow tyre (1.6-2.1BAR) |
| Vibrating System |
Eccentric Vibration moror, 300Hz |
| Centrifugal Force |
100 Kgs |
| Vibrating Plate |
Aluminium Alloy |
| Scraper Blade |
Aluminium Alloy |
| Scraper Adjustment |
Computer Control, Automatic Adjustment |
| Working Length |
5.6M |
| Reverse Speed |
2.5Km/H |
| Min. Ground Clearance |
355mm |
| Ground Flatness |
2mm |
| Ground Elevation Error |
7mm/100mm |
| Max Working Radius |
200mm |
| Working |
200m/h--350m/h |
| Efficiency/Hour |
|
| Dimension (L*W*H) |
2748 x 2900 x 2044 |
| Weight |
230 Kgs |
