| Engine Modal |
Kohler Ch620 |
| Engine Type |
Petrol, V-cylinder engine, air cooling |
| Engine Power (Kw) |
14.2 |
| Lubricanting Oil (L) |
2 |
| Fuel Tank Capacity (L) |
35 |
| Type of Leveling |
Independent Suspension, Center rotation |
| Paving Width (mm) |
2500 |
| Paving Way |
Scraper Blade Paving |
| Paving Thickness (mm) |
30-200 |
| Boom Motor |
High torque hydraulic motor |
| Vibrating System Control |
Vibrating Motor |
| Exciting Force (Kg) |
100 |
| Vibrational Frequency (hz) |
50 |
| Laser System Control Type |
Flat Scanning + High Sensitivity DC Push Road |
| Laser System Control Effect |
Flat Surface, Scope Floor |
| Driving System |
Hydraulic Driving Tyre |
| Wheel |
Heavy-duty tyre |
| Walking Speed (Km/h) |
0-2.5 |
| Forward/backward |
Switch Control, Stepless Speed |
| Turning |
Switch Control |
| Dimension |
3155 x 3175 x 1910 |
| Weight |
741 |
